Reflow Soldering Oven for SMT LED PCB Welding Machine 10 Zones Oven
Reflow Soldering Oven for SMT LED PCB Welding Machine 10 Zones Oven
- Name: SMT Reflow Oven
- Heating zones: 10
- Heating method: Hot Air
- Usage: SMT Assembly line
- Product description: Reflow Soldering Oven for SMT LED PCB Welding Machine 10 Zones Oven
reflow soldering oven for SMT LED PCB Welding Machine 10 Zones Oven
Introduction:
1. Windows XP platform, user friendly interface and easily swap between bilingual of English & Chinese.
2. Digital control system adopted with PLC and Modular circuit. Achieving high stability and repeatibility.
3. Intelligent diagnostic system (IDS) provides trouble remind, fault alert, list-out and SPC data record features.
4. Zone temperature and blower speed can be controlled Independently, to meet the high-precision requirements.
5. Effective heating zone length with uniform heat distribution.
6. Forced air cooling system with efficient cooling speed suits most kinds of lead-free soldering application.
7. PLC and PID closed loop control to achieve high precision temperature control.
8. Standard 10 couples of top and bottom zones with patented air management structure, more efficient hot air convection and faster thermal compensation.
9. The rail track is dealt with hardening process to make it more reliable.
10. Manual adjusted process track width whereas providing option of automatic by SPG gear motor.
11. Computerized controlled rail chain lubrication structure.
12. Powerful software system can save all settings and data printout capability.
13. Flux removal unit meet with environmental protection requirement.
14. Nitrogen structure is an option.
Specification:
Model
|
Flason R10
| |
Heating System
|
Number of heating zones
|
Top 10/Bottom 10
|
Number of cooling zones
|
3
| |
Heating Passage
|
3900mm
| |
Heating Style
|
Hot air
| |
Cooling Style
|
Air Oven: Forced air
| |
Exhaust Volume
|
10m³/min * 2 vanes
| |
Conveyor System
|
Max. Width of PCB
|
450mm
|
Mesh belt width
|
500mm
| |
Conveyor Direction
|
L→R(or R→L)
| |
Process Height
|
900±20mm
| |
Conveyor style
|
Mesh and chain
| |
Range of rail width
|
0-450mm
| |
Conveyor speed
|
0-2000mm/min
| |
Auto/manual Lubrication
|
Standard
| |
Fixed Track
|
Front track fixed(option: rear track fixed)
| |
Product Clearance
|
Top and bottom 25mm
| |
Control system
|
Power supply
|
5 cables 3 phase 380V 50/60Hz
|
Total consumption
|
50kw
| |
Startup consumption
|
48kw
| |
Steady consumption
|
10KW
| |
Ramp up time
|
About 20 mins
| |
Temp. set-point range
|
Room temperature-300℃
| |
Temp. control method
|
PID close loop control & SSR driving
| |
Temp. control precision
|
±1℃
| |
Temp. deviation on PCB
|
±2℃
| |
Data storage
|
Process Data and status storage(80GB)
| |
Nozzle plate
|
Aluminum Alloy Plate
| |
Abnormal Alarm
|
Abnormal temp. (overtemp/low temp.)
| |
Board dropped alarm
|
Light Tower: Amber-warming, Green-normal, Red-abnormal
| |
General
|
Dimension(L*W*H)
|
5710×1400×1550mm
|
Weight
|
2150KG
| |
Color
|
Computer grey
| |
Key words:
SMT reflow oven, soldering oven, SMT oven, SMT soldering reflow oven, smt assembly line reflow oven,PCB soldering reflow oven, SMT assembly oven, PCB soldering oven, LED reflow oven, LED PCB reflow oven.
Flason Electronic Co.,ltd provide a full SMT assembly line solutions, including SMT reflow oven, THT wave soldering machine, pick and place machine, solder paste printer,PCB loader, PCB unloader, chip mounter, SMT AOI machine, SMT SPI machine, SMT X-Ray machine, SMT assembly line equipment, PCB production Equipmentetc any kind SMT machines you may need, please contact usfor more information: wechat whatsapp:008613691605420, Skype: flasonsmt, Email: sales@flason-smt.com
FAQ
1) This is the first time I use this kind of machine, is it easy to operate?
There is English manual or guide video that show you how to use machine.
If you still have any question, please contact us by e-mail / skype/ phone /trademanager online service.
2) If machine have any problem after I receive it, how can I do ?
Free parts send to you in machine warranty period.
If the part is less than 0.5KG, we pay the postage.
If it exceeds 0.5KG, you need to pay the postage.
3) MOQ ?
1 set machine, mixed order is also welcomed.
4) How can I buy this machine from you? ( Very easy and flexible !)
A. Consult us about this product on line or by e-mail.
B. Negotiate and confirm the final price , shipping , payment methods and other terms.
C. Send you the proforma invoice and confirm your order.
D. Make the payment according to the method put on proforma invoice.
E. We prepare for your order in terms of the proforma invoice after confirming your full payment.
And 100% quality check before shipping.
F.Send your order by air or by sea.
5)Why choose us ?
A. Gold supplier on Alibaba !
B. Trade assurance to US$54,000 !
C. Best price & Best shipping & Best service !
